🛩️ .skyc — Skybrush show file (recommended)

The default export from Skybrush Studio. No conversion needed — just drag the file Skybrush produces straight into the uploader. Trajectories (cubic-Bezier waypoints) and LED programs are both read directly from the archive.

Coordinate convention is whatever you set in Skybrush; altitude maps to the vertical axis in the player. Source rate is sampled at 30 fps internally; output runtime is 6 fps to match the iOS app.

📦 .zip — one CSV per drone

Bundle every per-drone CSV into a single zip. Naming examples: Drone 1.csv, drone_42.csv, 1.csv (any name with a digit before .csv works). Drones in nested folders are fine.

Each CSV must have this header and one row per frame at 30 fps (33 ms intervals):

Time [msec],x [m],y [m],z [m],Red,Green,Blue
0,14.34,-13.40,84.85,152,149,141
33,14.34,-13.40,84.85,152,149,141
66,14.36,-13.40,84.88,160,149,141
99,...

x/y/z in meters. RGB columns are 0–255 and optional — if missing, drones default to black (0, 0, 0).

📐 .mat — MATLAB show file

Required variables: x, y, z — each a num_drones × num_frames matrix of floats. Optional: r, g, b (same shape, 0–255). Source sample rate: 30 fps.

% MATLAB example — 500 drones, 9000 frames (5 min @ 30 fps)
x = randn(500, 9000);   % size: [num_drones × num_frames]
y = randn(500, 9000);
z = abs(randn(500, 9000));
r = uint8(255 * ones(500, 9000));
g = uint8(  0 * ones(500, 9000));
b = uint8(  0 * ones(500, 9000));
save('show.mat', 'x', 'y', 'z', 'r', 'g', 'b');

NaN positions are allowed for "not yet active" drones — we forward-fill from the first real frame.

🎯 .jsdm — JSON show file

A JSON-based drone show description. Export directly from your design tool — no edits needed. We parse planeCount + frameCount and walk pointFrames / channelFrames in time order.

{
  "planeCount": 1200,
  "frameCount": 6600,
  "pointFrames": [
    { "time": 0, "points": [
      { "no": 1, "x": 0, "y": 0, "z": 0 },
      { "no": 2, "x": 1.5, "y": 0, "z": 0 }
    ]},
    { "time": 30, "points": [ ... ] }
  ],
  "channelFrames": [
    { "time": 0, "channels": [
      { "no": 1, "c1": 255, "c2": 0, "c3": 0 },
      { "no": 2, "c1":   0, "c2": 255, "c3": 0 }
    ]}
  ]
}

no is 1-indexed drone number. c1/c2/c3 are R/G/B (0–255).
